200-250W Drive Motor, PMDC Brushless Motor GF055AH
200-250W Drive Motor, PMDC Brushless Motor GF055AH
200-250W Drive Motor, PMDC Brushless Motor GF055AH
Technical Specifications
Rated Power (W) 200 250 200 250
Max. Power (W) 400 500 400 500
Rated Voltage(V) 36 36 36 36
No-load Current(A) ≤1.0 ≤1.2 ≤1.0 ≤1.2
No-load Revolution (RPM) 2300±5% 2250±5% 2300±5% 2250±5%
Rated Torque (N•m) 1.0 1.2 1.0 1.2
Max. Torque (N•m) ≥3.0 ≥4.0 ≥3.0 ≥4.0
Rated Revolution (RPM) 2000±5% 1950±5% 2000±5% 1950±5%
Rated Current(A) ≤8.0 ≤9.0 ≤8.0 ≤9.0
Rated Efficiency (%) ≥76 ≥76 ≥76 ≥76
Working Cycle (min.) S2-60 S2-60 S2-60 S2-60
Insulation Class E E E E
Protection Level IP33 IP33 IP33 IP33
Out-Shaft Length (L/mm) 30/37 30/37 30/37 30/37
Outer Diameter (D/mm) 83/90 83/90 90 90
Tire Replacement No No Yes Yes

Note: we can customize any brushless DC drive motors according to your application requirements and working conditions.
